Paul Horton's Welder Series Ford Godzilla Engine Mount Kit (Universal; Some Adaptation May Be Required)

Ford "Godzilla" 7.3L Motor Mount KitThis Ford "Godzilla" 7.3L motor mount kit is built for strength, versatility, and ease of installation, accommodating frames of various widths, from narrow T-buckets to full-size F100 pickups. The design is intended for easy assembly (in the ready-to-weld option), and provides a strong, professional look. Reinforced with gussets, the mount ensures reliable engine support, while urethane bushings effectively dampen vibrations, enhancing comfort and reducing stress on the mounting structure.High-Quality Materials and Flexible FitmentMain Plates and Gussets: Constructed from a 1/4" main plate with 3/16" gussets, the mount is engineered to secure even the high-power 7.3L engine in various setups.Four Bolt Mounting: Our mounts utilize four engine block mounting locations for added strength and stability.Trim-to-Fit Frame Plates: The kit includes 4 trim-to-fit 3/16" frame plates that can be customized to fit your frame dimensions once the engine location is set. Filler plates are provided to create a third side on the frame plates, adding extra support and stability to the mounting structure.Compatible with Multiple Ford EnginesIn addition to the Ford "Godzilla" 7.3L engine, this kit has also been successfully used for the 6.2L Ford Raptor engine, making it a versatile choice for various Ford builds. Whether you’re working on a classic truck or a high-performance setup, this mount kit is adaptable to your needs.Complete Mounting Kit for ConvenienceThe kit includes all necessary zinc-plated, grade 5 metric bolts and lock washers for secure, corrosion-resistant assembly. Available in both ready-to-weld and fully TIG welded configurations, the kit comes with both driver and passenger side engine plates.Kit Contents:4x #20494 trim-to-fit frame plates2x #27804 frame plate fillersDriver & Passenger 1/4" engine platesLarge 1-3/4" wide urethane bushings with outer tubes and inner sleeves3/16" gussets and top platesAll required zinc-plated, grade 5 hardwareFor builders choosing the ready-to-weld kit, the components come completely unwelded for customization. The fully TIG welded kit is professionally assembled, as shown in the main picture.With durability and versatility at its core, this mount kit provides a stable, customizable mounting solution for powerful Ford engines. For installation tips and best practices, check out our motor mounting tech tips.
