Factory Fit Engine Wiring Harness (1958 283 V8 Biscayne, Brookwood, Del Ray, Impala, Yeoman w/ Manual Transmission)

Item EK-40-901320
Clearance
4 Reviews of similar
Clearance Price

$154.99

Military, Medical & First Responders $7.75 Available in Eckler's Cash Rewards.
Confirm Eligibility

CONFIRM THIS FITS YOUR VEHICLE!

Select a different vehicle Help?
Update or Change Vehicle
Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program
    Join For FREE

      Product Information

      Features, Description, Q&A

      Features

        _x000D_
      • Factory Fit Engine Harnesses Manufactured According to Original General Motors Specifications
        • _x000D_
      • Fully Assembled, Taped, and Ready to Install Upon Arrival
        • _x000D_
      • Plugs Directly Into Firewall in Factory Location
        • _x000D_
      • Follows Original Routing in Engine Compartment
        • _x000D_
      • Combines Engine and Front Light Harness Functions for Early GM Vehicles
        • _x000D_
      • Includes Wiring for Ignition System, Starter, Heater Blower, Temperature, and Oil Pressure Sender Wires
        • _x000D_
      • Excludes Capillary Tube Oil Pressure Reading Circuits
        • _x000D_
      • Ignition Circuit Designed with Resistance for Ignition Point Longevity
        • _x000D_
      • Recommended to Order Modified Harness for High Energy Ignition (HEI) Systems
        • _x000D_
      • Consult Factory Service Manual or Sales Team to Confirm Part Numbers
        • _x000D_
      • Fits 1958 283 V8 Biscayne, Brookwood, Del Ray, Impala, and Yeoman with Manual Transmission
        • _x000D_

      Description


      Factory Fit engine harnesses are manufactured according to the original General Motors specifications. Each part number is fully assembled, taped and ready to install upon arrival. This harness will plug into the firewall in the factory location, and will follow original routing in the engine compartment. A combination of the engine and front light harness accomplish most functions under the hood of an early GM vehicle.

      Engine harness design varied significantly from year to year, but most will contain wiring for the ignition system, starter, heater blower, and temperature/oil pressure sender wires if applicable. Some vehicles used a capillary tube to provide an oil pressure reading, so these will not be included in a wiring harness. On vehicles with ignition points, the circuit feeding the ignition coil was designed with some resistance to extend the life of the ignition point set. Modern electronic ignition systems or High Energy ignition (HEI) systems do not require resistance in the circuit, so it is recommended that a harness modified for HEI be ordered if the ignition system has been upgraded. In most cases these harnesses are available in our catalog and feature unique part numbers.

      Please consult your factory service manual to determine if the engine harness for your vehicle will contain the circuits required for your project, or give our Sales team a call to confirm part numbers.

      Engine Harness For

      Chevrolet Fullsize 1958
      ENGINE HARNESS, V8, 283 c.i., F.I., manual trans
