Engine Wiring Harness, V8 396 c.i., HEI, With Console Gauges & TH400 Automatic Transmission (1970 Nova)

Item EK-85-294654-1
1 Reviews
Our Price

$294.99

Military, Medical & First Responders $14.75 Available in EK Cash Rewards.
Confirm Eligibility

Add to Cart
Save for later
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    or use

    Shop Owners Save More! Sign up for our dealer program
    Join For FREE
    Loading Indicator

      Product Information

      Features, Description, Reviews, Q&A

      Features

      • Factory Fit Engine Harnesses Manufactured According To Original General Motors Specifications
      • Fully Assembled, Taped, And Ready To Install Upon Arrival
      • Plugs Into Firewall In The Factory Location
      • Follows Original Routing In The Engine Compartment
      • Designed For Use Under The Hood Of Early GM Vehicles
      • Modified For A 12 Volt HEI Ignition System
      • Replaces Original Resistor Wire With Standard 12 Volt Feed
      • Includes Connector For GM Large Cap Distributor
      • Connector End May Need Replacement If Not Using GM Large Cap HEI Distributor
      • Engine Harness Varies By Year But Generally Includes Ignition, Starter, Heater Blower, And Temperature/Oil Pressure Sender Wiring
      • Some Vehicles Use Capillary Tube For Oil Pressure, Which Is Not Included In Harness
      • Consult Factory Service Manual Or Sales Team For Circuit Details And Part Number Confirmation
      • Fits 1970 Nova V8 396 Ci, With TH400 Automatic Transmission And Console Gauges. Modified For HEI Distributor

      Description

      Engine Wiring Harness Overview. The Eng Wiring Harn, V8 396, HEI, W/Console Gauges & TH400 A/T, 1970 provides a factory-spec replacement harness designed for Chevrolet Nova vehicles equipped with a 396 cubic inch V8 engine, TH400 automatic transmission, and console gauges. This harness supports the vehicle’s electrical needs under the hood, ensuring reliable operation of the ignition system, starter, heater blower, and essential sensor connections, specifically adapted for 12-volt HEI ignition systems.

      Construction and Appearance. Manufactured to meet original General Motors specifications, this engine harness is fully assembled and taped for immediate installation. The wiring is routed to match the factory original placement, featuring robust insulation and connectors designed to interface with GM large cap distributors. The finish is durable and built to withstand the conditions of the engine compartment environment.

      Installation. Installation is straightforward as the harness plugs directly into the firewall at the factory location and follows the original routing, minimizing the need for modification or additional drilling. This allows for an easier and cleaner installation process for restoration and restomod projects.

      Application. Designed specifically for the 1970 Chevrolet Nova equipped with a V8 396 ci engine, TH400 automatic transmission, and console gauges. This harness is modified specifically for HEI distributors; verifying distributor compatibility is necessary if using different distributor types.
